• Boss Katana 100/212 Gen 3 Guitar Amplifier
• 100 W power, To 12" speakers
• Power Control, CAB RESONANCE switch
• AMP TYPE button, VARIATION button
• 4 channels, STEREO EXPAND switch
• USB-C port for use as Audio Interface and for editing sounds

BOSS Katana 100/212 Gen 3 Guitar Amplifier

• Latest version of the popular Boss Katana series.
• Lots of new features.
• Improved sound quality and EQ.
• New Pushed Amp type that simulates a pushed vintage amplifier.
• Bluetooth Stream to audio and midi via adapter (optional).
• Edit sounds directly from your phone via Tone Studio App, via bluetooth.
• Stereo headphone output.
• Improved editor - more intuitive layout.
• Katana 100/212 Gen 3 Guitar Amplifier.
• 100 W power, ideal for both rehearsal rooms and live performances.
• Two 12" speakers deliver powerful and clear sound.
• Power Control: STANDBY, 0.5 W, HALF, MAX settings for flexible volume adjustment.
• CAB RESONANCE switch: VINTAGE, MODERN, DEEP for adjusting the cabinet resonance.
• Controls: PRESENCE, MASTER and SOLO buttons for precise sound control.
• AMP TYPE button: ACOUSTIC, CLEAN, PUSHED, CRUNCH, LEAD, BROWN options for different tonal options.
• VARIATION button for additional tonal nuances.
• Equalizer: BASS, MIDDLE, TREBLE buttons and CONTOUR knob for comprehensive tone shaping.
• Effects section: BOOSTER, MOD, FX, DELAY, REVERB buttons with dedicated controls.
• TAP knob for adjusting tempo for delay and modulation rates.
• Tone settings: CH1, CH2, CH3, CH4 and PANEL buttons for easy access to presets.
• STEREO EXPAND switch for extended sound experience.
• Connect computer via USB-C and use it as Audio Interface and for editing sounds.

- Rated Power Output
100 W

- Nominal Input Level
INPUT: -10 dBu (1 M ohms)
AUX IN: -10 dBu (20 k ohms)
RETURN IN: -10 dBu (100 k ohms)

- Speaker
30 cm (12 inches) x 2

- Controls
POWER switch
PRESENCE knob
MASTER knob
SOLO button
POWER CONTROL switch (STANDBY, 0.5 W, HALF, MAX)
CAB RESONANCE switch (VINTAGE, MODERN, DEEP)

[AMPLIFIER]
VARIATION button
AMP TYPE knob (ACOUSTIC, CLEAN, PUSHED, CRUNCH, LEAD, BROWN)
GAIN knob
VOLUME knob

[EQUALIZER]
CONTOUR button
BASS knob
MIDDLE knob
TREBLE knob

[EFFECT]
BOOSTER button
MOD button
FX button
DELAY button
REVERB button
TAP button
BOOSTER knob
MOD knob
FX knob
DELAY knob
REVERB knob

[TONE SETTING]
CH1 button
CH2 button
CH3 button
CH4 button
PANEL button

[STEREO EXPAND]
STEREO EXPAND switch

- Indicators
VARIATION
ACOUSTIC
CLEAN
PUSHED
CRUNCH
LEAD
BROWN
CONTOUR
BOOSTER
MOD
MOD FX
FX DELAY
REVERB
TAP
SOLO
CH1
CH2
CH3
CH4
PANEL

- Connectors
INPUT jack: 1/4-inch phone type
POWER AMP IN jack: 1/4-inch phone type
LINE OUT jack: 1/4-inch phone type
SEND jack: 1/4-inch phone type
RETURN jack: 1/4-inch phone type
STEREO PHONES jack: Stereo 1/4-inch phone type
EXP PEDAL jack: 1/4-inch TRS phone type
GA-FC/CTL CH1/CH2 SOLO jack: 1/4-inch TRS phone type
AUX IN jack: Stereo miniature phone type
USB port: USB C type
BLUETOOTH ADAPTOR SLOT: Bluetooth Audio MIDI Dual Adaptor
AC IN jack

- Power Consumption
77 W

- Dimensions (Include handle and rubber feets)
670 (W) x 248 (D) x 484 (H) mm
26-7/16 (W) x 9-13/16 (D) x 19-1/16 (H) inches

- Weight
19.8 kg
43 lbs 11 oz

- Accessories
Owner's manual
Power cord
GA-FC sticker

- Options (sold separately)
Footswitch: BOSS FS-5L, BOSS FS-6, BOSS FS-7
Expression pedal: Roland EV-5, BOSS EV-30, BOSS FV-500L, BOSS FV-500H
GA FOOT CONTROLLER (GA-FC, GA-FC EX)
Bluetooth Audio MIDI Dual Adaptor (Model BT-DUAL)
Amplifier Stand: BAS-1

* 0dBu=0.775 Vrms
